40 Tons Side Wall Trailer For Sale

Genron’s 40 Tons Side Wall Trailer has a deadweight of approximately 7.5 tonnes. It has standard dimensions of 12,600mm long, 2,500mm wide, and 3,000mm high. This means it has a powerful load capacity. It has a capacity of up to 40 tonnes. It is ideal for transporting heavy goods, such as industrial materials and agricultural products. The use of FUWA, BPW or Huajing axles with 12.00R22.5 tyres of ROAD STAR and TRIANGLE brands ensures stability and safety. It is an extremely high-performance sidewall trailer. It can be customized to meet different transport needs according to specific customer requirements.

Specification

Detail	Specification
Tare Weight	About 7.5 tons
Dimension	12600mm2500mm3000mm (Size can be choose freely)
Loading Capacity (T)	40T
Axle	13 T/12T, FUWA /BPW /Huajing Brand
Tires	12.00R22.5 etc, ROAD STAR brand, TRIANGLE brand etc.
Rim	6.5-20/7.5-20/8.00-20/8.5-20 (Special for export market)
Suspension	Mechanical suspension (Germany Type or America Type) Or Air suspension (China brand or BPW brand ) (Special for export market)
Spring leaf	90(W)mm13(Thickness)mm10 Layer or 100mm12mm12 (Special for export market)
King pin	JOST brand 2.0 or 3.5inch bolts type or Welding type
Support leg	JOST A300C or Genron 28Tons (Double speed)
Main beam	Height: 490mm, upper plate is 14mm, middle plate is 8mm down plate is 14mm ; Material is 700L Steel .
Ladder	Manual ladder or Hydraulic ladder
Light	LED light
Twist Locks	Four ,Eight or Twelve pieces (Lifting type or Twist Screw Type)
Receptacle	7 ways (7 wire harness)
Tool box	One piece, 1m脳0.5m脳0.5m (Size can be choose freely)(equipped with 1 unit Tire spanner,1 unit gudgeon sleeve and 1 unit cranking bar)
Painting	Complete Chassis sand blasting to clean rust, 1 coat of anticorrosive prime, 2 coats of final paint

40 tons sidewall Trailer Design Drawings

The 40-ton sidewall semi-trailer refers to a semi-trailer with a sidewall board for carrying goods. Its carriage is open. It consists of a row of sidewalls. It is mainly suitable for medium to long-distance transportation. The sidewall semi-trailer is a vehicle. It can load a wide range of goods, including long, wide, and high items like steel, wood, and stone. Loading and unloading obstacles are relatively small for large equipment transportation. This allows loading almost all goods within the bearing range. Here are our sidewall semi-trailer design drawings for your reference.

40 tons sidewall Trailer Advantages

Mature Welding Process: The GENRON VEHICLE uses automatic submerged arc welding for construction. It reinforces key points and avoids some parts that are easier to lose welding, according to experience. This supports the vehicle working for a longer time without needing repairs.

Reliable Materials: GENRON VEHICLE uses high-strength steel to manufacture the flatbed trailer. This increases the trailer’s loading capacity and service life. In addition, all the main parts used in our trailers must be processed with advanced equipment. They must also have good reputations in the market.

Quality Axle suspensions and Brake system: Genron Vehicle BPW and FUWA are the best axles worldwide. They work with a WABCO brake valve for more effective braking, which ensures safety and saves tire costs. Quality springs and suspensions ensure longer service life and save maintenance costs.

Mature Design and Manufacture: GENRON VEHICLE would like to design the trailer according to our customers’ needs and special use conditions. Additionally, we would consider more than their final usage. We then provide customers with reasonable suggestions when they are hesitating.

Rich experience: GENRON VEHICLE has more than 20 years of experience producing and exporting trailers and other goods. It has helped hundreds of customers in over 35 countries in Africa and Southeast Asia.

Quality Assurance: GENRON VEHICLE offers a 2-year warranty for the chassis frames of our trailers. We also provide spare parts support services. We are responsible for damage to parts during normal use.

The Use Of 40 tons sidewall Trailer

Transporting bulk cargoes: 40-ton sidewall trailers are also suitable for transporting cargoes. If you have a 1.2m sidewall, you can transport sandbags, rice bags, and so on. If you have a 1m sidewall, you can transport cement bags, coal cinder, and copperplate.

Customer Feedback

The GENRON 40-ton sidewall semi-trailer for sale is becoming more popular in the market. It is known for its durable quality and good reputation. And we have exported more than 1000 units of various styles of sidewall semi-trailers all over the world.

sidewall Trailer Tech Support

GENRON VEHICLE has a professional technical design team. If you are uncertain about your products or your design, we can visit you, help you check and analyze your market, and give you a special design that fits your country. Our records show more than 11 years of overseas visits and exporting business experience. We focus on the trailer and truck fields. That’s why we can quickly provide you with the right product.
